NEW QUESTION 1
When a new instance and new VMs are added to ACP 4200, additional VLANs are added to the ACP 4200. To what are these VLANs added?

• A. The VSP Switches only.
• B. The ESXi Hosts only.
• C. The VSP Switches and ESXi Hosts.
• D. The VSP Switches, the ESXi Hosts, and the existing VMs.

Answer: C

NEW QUESTION 2
Refer to the exhibit.

Which Avaya Session Border Controller for Enterprise (ASBCE) configuration option is shown?

• A. High Availability
• B. Hybrid
• C. Geographic Redundancy
• D. Two-wire

Answer: A

NEW QUESTION 3
Refer to the exhibit.

What does the IP address 10.1.1.1 represent?

• A. The IP address of the EMC storage
• B. The SMLT IP address of the two VSP 7200 switches
• C. The Virtual IST IP address of the two VSP 7200 switches
• D. The VRRP IP address of the two VSP 7200 switches

Answer: D

NEW QUESTION 4
Which two are valid levels of VMware performance monitoring? (Choose two.)

• A. Visualization Performance and Fault Manager (VPFM)
• B. Virtual Machine (VM)
• C. Data Center (DC)
• D. Host

Answer: BD

NEW QUESTION 5
Refer to the exhibit.

An administrator navigates to the Avaya Orchestrator link shown in the exhibit. What would the Administrator be able to monitor here?

• A. A list of Services with status of Warning or Critical.
• B. A list of Services with status of OK.
• C. A list of Services regardless of status.
• D. A list of Services which have additional details.

Answer: D

NEW QUESTION 6
What is a benefit of using Virtual Router Redundancy Protocol (VRRP) on the VSP switches in the ACP 4200?

• A. It creates virtual Layer 2 connections for the VMs.
• B. It allows you to connect to the switches for management access.
• C. It ensures the end systems do not need to change their gateway IP address in the event of a fail-over.
• D. It allows the end systems to automatically change their gateway IP address in the event of a fall-over.

Answer: D

NEW QUESTION 7
Using VMware networking in ACP 4200, how are Virtual NICs mapped to physical NICs?

• A. Via DRS rules
• B. On a 1-to-1 basis
• C. Via Virtual Switches and Port Groups
• D. Via the VNIIC mapping tables

Answer: D

NEW QUESTION 8
An ACP 4200 engineering team is considering deploying an Extension Rack. What is the purpose of the Extension Rack?

• A. When the Main rack is not functioning properly the Extension Rack will take over for the main.
• B. When all hardware components cannot fit into the Main ACP Rack, Extension Racks are used for additional physical appliances and servers.
• C. When full redundancy is needed, Extension Racks are used for additional physical appliances and servers.
• D. When the number of telephone extensions on the Avaya Aura® applications exceed the recommended limit, Extension Racks are used to host additional media resources to support a higher limit.

Answer: C

NEW QUESTION 9
Refer to the exhibit.

An administrator is trying to add a new VSP to the ACP 4200 rack. However, when the Configuration Wizard is run and the 'Detect Hardware' button is clicked, the VSP cannot be detected.
What is potentially causing this to happen?

• A. The VSP has not been configured with the correct slot in Configuration Wizard.
• B. The VSP has not been configured with the correct Device Description in Configuration Wizard.
• C. The VSP has not been configured with the correct Protocol in Configuration Wizard.
• D. The VSP's device credentials has not been configured correctly in System Manager.

Answer: D

NEW QUESTION 10
How would an administrator display the IP addresses of the VSP switches of the ACP 4200 within the Avaya Orchestrator Home Dashboard?

• A. By right-clicking on the Dashboard menu item and downloading the network summary report.
• B. By right-clicking on the Admin menu item and downloading the network summary report.
• C. By right-clicking on the Report menu item and downloading the network summary report.
• D. By hovering the mouse pointer over the Up status indicator within the Network dashlet.

Answer: B

NEW QUESTION 11
Refer to the exhibit.

An administrator is adding new equipment to the ACP 4200 in the Avaya Orchestrator Configuration Wizard. How do the Device Description and Serial Number fields get populated in the Avaya Orchestrator
Configuration Wizard?

• A. These are optional fields that do not need to be populated.
• B. These are automatically detected by clicking on the Detect Hardware button.
• C. These are manually entered by the administrator.
• D. These are imported from the ACP Configurator Tool Excel spreadsheet.

Answer: C

NEW QUESTION 12
Which statement about the Nimble Storage used in ACP 4200 4.0 is true?

• A. It is connected directly to the ESXi hosts via multiple 10G links.
• B. It is connected directly to the ESXi hosts via multiple 1G links.
• C. It is connected to the network switches via multiple 10G links.
• D. It is connected to the network switches via multiple 40G links.

Answer: C

NEW QUESTION 13
Refer to the exhibit.

The CPU performance of Communication Manager (CM) shows a significant difference depending on the call rates.
Which statement about making configuration changes is true?

• A. Increasing the number of Virtual CPUs allocated to CM might help to reduce this difference.
• B. Ensuring that a secondary CM is available to allow for load-balancing might help to reduce this difference.
• C. Migrating the CM Virtual Machine to another ESXi host that is less busy might help to reduce this difference.
• D. Reducing this difference is not necessary because this is expected behavior.

Answer: B

NEW QUESTION 14
Refer to the exhibit.

In the deployment shown in the exhibit, how is High Availability achieved across the two Data Centers?

• A. By ensuring that the L2 VLANs are extended across to both Data Centers.
• B. By managing both Data Centers using the same vCenter Server and using vMotion and DRS.
• C. By using Virtualization Provisioning Service (VPS) to automate the provisioning of the network hardware and vSwitches across the two Data Centers.
• D. By using Avaya Aura® Application High Availability features.

Answer: C

NEW QUESTION 15
An Avaya Orchestrator administrator is asked to check the CPU usage for the last 24 hours of one of the ESXi Hosts, as it has been performing erratically.
How can the administrator go about doing this?

• A. By clicking on the Compute Group's Service State line.
• B. By navigating to Quick View – All Host Problems.
• C. By going to the Performance Graphs of the CPU Usage Service for the host.
• D. By selecting the VM Group's Service State line.

Answer: A
