Regenerate TMOS Administration 201 Exams

NEW QUESTION 1
A BIG-IP Administrator contacts F5 Support, which identifies a suspected hardware failure. Which information should the BIG-IP Administrator provide to F5 Support?

• A. Qkview, EUD output
• B. Qkview, UCS archive, core files
• C. Qkview, part numbers for failed components
• D. Qkview, packet capture, UCS archive

Answer: A

NEW QUESTION 2
Assume the bigd daemon fails on the active system. Which three are possible results? (Choose three.)

• A. The active system will restart the bigd daemon and continue in active mode.
• B. The active system will restart the tmm daemon and continue in active mode.
• C. The active system will reboot and the standby system will go into active mode.
• D. The active system will failover and the standby system will go into active mode.
• E. The active system will continue in active mode but gather member and node state information from the standby system.

Answer: ACD

NEW QUESTION 3
A BIG-IP Administrator remotely connects to the appliance via out-of-band management using https://mybigip mycompany net. The management portal has been working all week. When the administrator attempts to login today, the connection times out. Which two aspects should the administrator verify? (Choose two)

• A. DNS is property resolving the FQDN of the device.
• B. The device is NOT redirecting them to http.
• C. The administrator has the latest version of the web browser.
• D. Packet Filters on the device are blocking port 80.
• E. The administrator has TCP connectivity to the device.

Answer: AE

NEW QUESTION 4
When can a single virtual server be associated with multiple profiles?

• A. Neve
• B. Each virtual server has a maximum of one profile.
• C. Ofte
• D. Profiles work on different layers and combining profiles is common.
• E. Rarel
• F. One combination, using both the TCP and HTTP profile does occur, but it is the exception.
• G. Unlimite
• H. Profiles can work together in any combination to ensure that all traffic types are supported in a given virtual server.

Answer: B

NEW QUESTION 5
A BIG-IP Administrator needs to view the CPU utilization of a particular Virtual Server. Which section of the Configuration Utility should the administrator use for this purpose?

• A. Statistics > Module Statistics > Local Traffic > Virtual Addresses
• B. Statistics > Module Statistics > Traffic Summary
• C. Statistics > Analytics > Process CPU Utilization
• D. Statistics > Module Statistics > Local Traffic > Virtual Servers

Answer: D

NEW QUESTION 6
A virtual server is defined using a source address based persistence profile. The last five connections were A, B, C, A, C . Given the conditions shown in the graphic, if a client with IP address 205.12.45.52 opens a connection to the virtual server, which member will be used for the connection?

• A. 10.10.20.1:80
• B. 10.10.20.2:80
• C. 10.10.20.3:80
• D. 10.10.20.4:80
• E. 10.10.20.5:80

Answer: B

NEW QUESTION 7
Assuming other failover settings are at their default state, what would occur if the failover cable were to be disconnected for five seconds and then reconnected?

• A. As long as network communication is not lost, no change will occur.
• B. Nothin
• C. Failover due to loss of voltage will not occur if the voltage is lost for less than ten seconds.
• D. When the cable is disconnected, both systems will become activ
• E. When the voltage is restored, unit two will revert to standby mode.
• F. When the cable is disconnected, both systems will become activ
• G. When the voltage is restored, both systems will maintain active mode.

Answer: C

NEW QUESTION 8
Refer to the exhibit
The BIG-IP Administrator is unable to access the management console via Self-IP 10.10 1.33 and port 443. What is the reason for this problem?

• A. Packet Filter needs to be configured to allow a source
• B. Self IP is configured to allow TCP All
• C. Self IP is configured to allow UDP 443
• D. Packet Filter is configured to allow port 443

Answer: C

NEW QUESTION 9
A site would like to ensure that a given web server's default page is being served correctly prior to sending it client traffic. They assigned the default HTTP monitor to the pool. What would the member status be if it sent
an unexpected response to the GET request.?

• A. The pool member would be marked offline (red).
• B. The pool member would be marked online (green).
• C. The pool member would be marked unknown (blue).
• D. The pool member would alternate between red and green.

Answer: B

NEW QUESTION 10
A site wishes to perform source address translation on packets from some clients but not others. The determination is not based on the client's IP address, but on the virtual servers their packets arrive on. What could best accomplish this goal?

• A. A SNAT for all addresses could be defined, and then disable the SNAT processing for select VLANs.
• B. Some virtual servers could be associated with SNAT pools and others not associated with SNAT pools.
• C. The decision to perform source address translation is always based on VLA
• D. Thus, the goal cannot be achieved.
• E. The decision to perform source address translation is always based on a client's address (or network).Thus, this goal cannot be achieved.

Answer: B

NEW QUESTION 11
A BIG-IP Administrator needs to install a HotFix on a standalone BIG-IP device, which has HD1.1 as the Active Boot Location. The BIG-IP Administrator has already re-activated the license and created an UCS archive of the configuration. In which sequence should the BIG-IP Administrator perform the remaining steps?

• A. Install HotFix in HD 1.1, Reboot the BIG-IP devic
• B. Install UCS Archive
• C. Install HotFix in HO 1.2, Install base Image in HD 1.2, Activate HD1.2
• D. Install base Image in HD1.2, Install HotFix in HD1.2, Activate HD 1.2
• E. Activate HD 1.2, Install base image in HD 1.2. Install HotFix in HD 1.2

Answer: C

NEW QUESTION 12
What is required for a virtual server to support clients whose traffic arrives on the internal VLAN and pool members whose traffic arrives on the external VLAN?

• A. That support is never available.
• B. The virtual server must be enabled for both VLANs.
• C. The virtual server must be enabled on the internal VLAN.
• D. The virtual server must be enabled on the external VLAN.

Answer: C

NEW QUESTION 13
Under what condition must an appliance license be reactivated?

• A. Licenses only have to be reactivated for RMAs no other situations.
• B. Licenses generally have to be reactivated during system software upgrades.
• C. Licenses only have to be reactivated when new features are added (IPv6, Routing Modules, etc) no other situations.
• D. Neve
• E. Licenses are permanent for the platform regardless the version of software installed.

Answer: B

NEW QUESTION 14
How is persistence configured?

• A. Persistence is an option within each pool's definition.
• B. Persistence is a profile type; an appropriate profile is created and associated with virtual server.
• C. Persistence is a global setting; once enabled, loadbalancing choices are superceded by the persistence method that is specified.
• D. Persistence is an option for each pool membe
• E. When a pool is defined, each member's definition includes the option for persistence.

Answer: B

NEW QUESTION 15
Refer to the exhibit.

A pool member fails the monitor checks for about 30 minutes and then starts passing the monitor checks. New traffic is Not being sent to the pool member.
What is the likely reason for this problem?

• A. The pool member is disabled
• B. Monitor Type is TCP Half Open
• C. Manual resume is enabled
• D. Time Until Up is zero

Answer: C

NEW QUESTION 16
A virtual server at 10.10.1.100:80 has the rule listed below applied.
when HTTP_REQUEST { if {[HTTP::uri] ends_with "htm" } { pool pool1 } else if {[HTTP::uri] ends_with "xt" } { pool pool2 }
If a user connects to http://10.10.1.100/foo.txt which pool will receive the request?

• A. pool1
• B. pool2
• C. Non
• D. The request will be dropped.
• E. Unknow
• F. The pool cannot be determined from the information provided.

Answer: B

NEW QUESTION 17
A BIG-IP Administrator is creating a new Trunk on the BIG-IP device. What objects should be added to the new Trunk being created?

• A. Interfaces
• B. Network routes
• C. VLANS
• D. IP addresses

Answer: A

Explanation:
trunk is a portchannel, you need to add a physical interface.

NEW QUESTION 18
Refer to the exhibit.

A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue?

• A. Set Protocol to UDP
• B. Set HTTP Profile to None
• C. Set Source Address to 10.1.1.2
• D. Set Destination Addresses/Mask to 0.0.0.0/0

Answer: B

NEW QUESTION 19
Given that VLAN failsafe is enabled on the external VLAN and the network that the active BIG-IP's external VLAN is connected to has failed, which statement is always true about the results?

• A. The active system will note the failure in the HA table.
• B. The active system will reboot and the standby system will go into active mode.
• C. The active system will failover and the standby system will go into active mode.
• D. The active system will restart the traffic management module to eliminate the possibility that BIG-IP is the cause for the network failure.

Answer: A
